| Product Specifications |
|---|
| Network interface | |
| GPON interface | 8 x GPON (2.5/1.25 Gbps) |
| 10GE Ethernet | 2 x 10GE SFP+ |
| 1GE Ethernet | 4 x RJ-45 + 2 x SFP+ |
| PON interface | |
| GPON | ITU-TG.984.x standard |
| Local Management interface | |
| Console | RJ-45 EIA/TIA-232 Console management port |
| MGMT | 1000BASE-T out-band management port |
| Performance | |
| Switching Capacity | 82 Gbps |
| Split ratio | 1:128 |
| Maximum ONU quantity | 4096 GEM port IDs, 1024 T-CONT, 1024 ONT |
| Power Supply and Consumption | |
| Power Adapter | AC Input: 100 to 240 V AC, 50/60 Hz; DC Input : 36 V-75 V |
| Redundancy Design | Pluggable double power supply, double AC, double DC, and AC+DC |
| Consumption | ＜70 W |
| Environmental conditions | |
| Storage | temperature -10 to 70°C, rel. humidity 10–90% (non-condensing) |
| Operation | temperature 0 to 45°C, rel. humidity 10–90% (non-condensing) |
| Physical specifications | |
| Dimensions | 440 mm × 362 mm × 44 mm (W * D *H) |
| Weight | 4.95 kg |
| Ethernet switching (L2) features | |
| VLAN | 4K VLAN entries |
| Port-based QinQ and Selective QinQ (StackVLAN) | |
| Port-based/MAC-based/IP subnet-based VLA | |
| Spanning tree | IEEE 802.1x STP/RSTP/MSTP |
| ONU remote loop detection | |
| MAC | MAC Black Hole |
| Port MAC limit | |
| 64K MAC address | |
| Port | Bi-direction bandwidth control |
| Port mirroring and traffic mirroring | |
| Service features | |
| Multicast | IGMPv1/v2/v3 |
| IGMP Snooping/Proxy | |
| IGMP filtering | |
| QoS | Base on port or user-defined rate limitation |
| Base on port or user-defined priority tag, provide 802.1P and DSCP tag ability of priority | |
| Base on port or user-defined high-grade queue scheduling | |
| Priority queues and schedulers of SP, WRR, and SP+WRR | |
| Congestion avoidance system | |
| Routing | BGP/MPLS/RIP |
| Security features | |
| User security | Anti-ARP-spoofing deceives and defends. |
| Anti-ARP-flooding flooding attack automatic control | |
| IP, MAC, port, and VLAN binding | |
| Port isolation | |
| Device security | Defend DOS attacks. |
| Security IP login through Telnet | |
| Hierarchical management and password protection of users | |
| Network security | IP address, VLAN ID, MAC address, and port manual binding |
| Port broadcast/multi-broadcast restrain | |
| Base on source/destination MAC address, VLAN, 802.1p, ToS, DiffServ, source/destination IP (IPv4/IPv6) address, TCP/UDP port number, protocol type of IP package flow classify and flow-defined regulation management, support package header 80-byte depth L2-L7 ACL flow filtrate |
|
| Dynamic ARP table-based binding | |
| DHCP Option82 and PPPoE+ upload user’s physical location | |
| Network management | Command-line interface（CLI）, Console, Telnet and WEB configuration |
| RMON (Remote Monitoring)1/2/3/9 groups of MIB | |
| System configuration with SNMPv1/v2/v3 | |
| NTP(Network Time Protocol) | |
| NMS2000 network management |
